0.25mm Pre Painted Galvalume Sheet Coil CGCH
| Place of Origin | Shandong,China |
|---|---|
| Brand Name | Shandong TISCO |
| Certification | MTC ISO9001 |
| Model Number | Color coated steel coil |
| Minimum Order Quantity | 3 Tons |
| Price | Discuss |
| Packaging Details | PVC+ waterproof paper + strong sea-worthy wooden package<br>If you need samples, we can provide them free of charge |
| Supply Ability | 5000 Ton/Tons per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard | AiSi, ASTM, Bs, DIN, GB, JIS | Grade | Galvanized Steel Coil |
|---|---|---|---|
| Type | Steel Coil, Color Coated Steel Sheet | Technique | Hot Rolled, Prepainted |
| Surface Treatment | Coated | Application | Decoration, Manufacturing, Industry, Building. |
| Width | 600mm-1500mm | Length | 1000-12000mm |
| Tolerance | ±3% | Processing Service | Bending, Welding, Decoiling, Cutting, Punching, Polishing |
| High Light | Pre Painted Galvalume Sheet Coil MTC,Pre Painted Galvalume Sheet Coil CGCH,0.25mm CGCH Prepainted Gi Steel Coil |
||
Product Description
0.25mm Pre-Painted Hot Dipped 5% Al-Zn Color Coated PVDF Film PPGL Steel Coil
PRODUCT DESCRIPTION
PPGL Coil is prepared by combining Zinc Coated Steel Sheets and 55% Aluminum.
The resulting product then has to be coated with Organic substances. Finally, it has to undergo a
Paint Coating. This step is what results in the term 'pre-painted'.
0.25mm Pre-Painted Hot Dipped 5% Al-Zn Color Coated PVDF Film PPGL Steel Coil
Advantages
Color-coated aluminum coil is one of the top decorative materials. The aluminum alloy has very stable performance and is not easy to be corroded. By coloring the surface of the aluminum alloy, the surface layer can be guaranteed not to fade for at least 30 years after special treatment.
specifications
| Grade | CGCC,CGCH,G550,DX51D,DX52D,DX53D |
| Thickness | 0.12-4.0mm |
| Width | 600-1500mm |
| Length | 1000-12000mm |
| Zinc Coating | Z40-600 g/m2 |
| Coating Thickness | Top-15-35, Back 5-15 |
| Color | RAL Color |
| Surface |
Matt,High gloss,Color with two sides,Wrinkle, Wooden color,Marble |
| Coil Weight | 2-5tons |
Chemical Composition
| Grade | C≤ | Mn | P≤ | S≤ | Si≥ | Cr≤ | Cu≤ | Mo≤ | Ni≤ | V≤ |
| A | 0.25 | 0.27-0.93 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
| B | 0.30 | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
| C | 0.35 | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
